Control systems for machines and cranes
Components for industrial automation
In cooperation with Giovenzana International B.V., Switch GmbH offers high-quality components for industrial automation. Particularly noteworthy are:
- Cam switch
- Load disconnector
- Limit switches with die-cast or plastic housings
- Safety limit switch
- Foot switch
These products offer reliable and powerful solutions for your automation needs.
The product portfolio is rounded off by an extensive range of energy supply systems using busbar systems up to 320 A.
Phoenix - Cam switch
PO – PX – CO – CX – G – Series
Phoenix cam switches have a current carrying capacity of 12 to 200 A. Different mounting options offer a high degree of flexibility during installation.
A large number of switching and circuit variants are available for every application. Special customer-specific variants are available on request.
Regolus - Switch disconnector
SQ and SQN series
Regolus switch-disconnectors offer a current carrying capacity of 25 to 160 A. There are versions for front, base and DIN rail mounting. Versions with 2, 3 and 4 poles as well as a central toggle and continuous shaft are available.
The switch-disconnectors can be combined with 2- and 3-pole fuse holders up to 32 A.
Pegasus - Accessories for control devices
With the Pegasus series, complete operating units with up to 6 control devices can be put together.
The main features are:
- Fastening via ø 22.5 mm mounting hole
- Protection class IP65
- With black or chrome-plated protective ring
- Emergency stop switch according to EN 418
- Contact via cage clamp, screw or PCB solder connection
Limit switch
FTN – FTN1R – FTNG – FCT – STNK – Series
The limit switches offered by Switch GmbH are used in a wide variety of applications in the automation sector. They meet all the requirements of the relevant standards. They are designed up to protection class IP67.
Microswitch
MFI – Series
The microswitches are equipped with self-cleaning contacts. The high-precision toggle switches are available with different connections.
Safety foot switch
IP series
Single or double foot switches are available with an optional emergency stop switch in accordance with EN ISO 13850, optionally with electrical or pneumatic contacts.
Conductor rails
The range includes busbars from 40 to 320 A in the highest configuration level. Versions with up to 7 poles are available.
The conductor rails meet the relevant international standards. They impress with their safe operation, simple installation and high reliability.
Housing for explosive atmospheric conditions
ATEX and IECEx enclosures
Switch GmbH also offers enclosures that comply with the ATEX94/9/EC directive.
ATEX is derived from the French abbreviation for ‘ATmosphères EXplosibles’ and currently refers to 2 European standards. These refer to resistance in explosive atmospheres. The enclosures are therefore suitable for environments where there is a high risk of explosion.
Limit switch for explosive atmospheric conditions
ATEX and IECEx limit switches
Switch GmbH now also offers limit switches that comply with the ATEX2014/34/EU directive. The FCT-EX limit switches are a series of thermoplastic, pre-wired limit switches with a permanently mounted cable. The cable can be routed both laterally and vertically out of the housing. The limit switches are available with 2 different microswitches and 10 different actuators.
